SCISSOR LIFT DUMP SERIES

Bed Size: 72" x 10'

Axles: Tandem 3500 lb. (1590 kg.)

Brakes: Electric, one axle, (2nd optional)

Suspension: Double eye, leaf spring

GVWR: 3150 kg. (7000 lb.)

Tires: 14" LRC, 5 Bolt

Tarp Kit: Optional

Sides: 16" + plank (plank not supplied)

Floor: 1/8" steel plate

Doors: Barn

Lighting: Standard Surface Mounted

Coupler: 2 5/16" A-Frame

Jack: 2000 lb.

Cylinder: 4" piston, scissor unit

Tool Box: Steel, Pump & Battery inside

Charge Line: Standard, 12V

Curb Weight: 940 kg.

Bed Size: 72" x 10'

Axles: Tandem 5200 lb. (2363 kg.)

Brakes: Electric 4 wheels

Suspension: Heavy duty slipper, leaf spring

GVWR: 4540 kg. (9988 lb.)

Tires: 15" LRC, 6 Bolt

Tarp Kit: Optional

Sides: 16" + plank (plank not supplied)

Floor: 1/8" steel plate

Doors: Barn

Lighting: Rubber Mounted Sealed

Coupler: 2 5/16" Adjustable

Jack: 7000 lb. Drop Leg

Cylinder: 5" piston, scissor unit

Tool Box: Steel Pump & Battery Inside

Charge Line: Standard, 12V

Curb Weight: 1230 kg.
